SustaPEEK CM LD přírodní
PEEK
Lighter, more efficient, more powerful - your advantage in lightweight construction.
SustaPEEK® CM LD was specially developed for demanding lightweight construction applications. The abbreviation LD stands for Low Density - and that is exactly what makes the difference: less weight (up to 30%) , more efficiency.
Manufactured using a high-quality hot pressing process, SustaPEEK® CM LD impresses with extremely low residual stresses and minimal distortion - for maximum dimensional accuracy and process reliability.
Whether higher loads, faster processes or reduced energy costs - with this high-performance solution you get more out of your process. Rely on intelligent lightweight design and secure your efficiency advantage.
Characteristics
- Low weight
- High dimensional stability
- Good thermal stability
- Good mechanical properties
- Flame retardant
- Chemical resistant
SustaPEEK CM (compression mould) is available with MOQ 1pcs in dimension 395x395mm in various thicknesses.
Daniel Bröder - Product Manager - Business Development, Mail: dbroeder@roechling.com
Variants
| SKU | Name | Type | Type | Color | Measurements | Length | Width | Thickness | Height | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
| No stock item (MOQ) | 883545 | SustaPEEK CM LD natural pressed | sheet | sheet | natural | 16 x 395 x 395 mm | 395 mm | 395 mm | 16 mm |
Technical Specifications SustaPEEK CM LD natural
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Hustota | DIN EN ISO 1183-1 | g / cm3 | 0,95 |
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Prodloužení při přetržení | DIN EN ISO 527 | % | 2 |
| Modul pružnosti v tahu | DIN EN ISO 527 | MPa | 4700 |
| Pevnost v tahu | DIN EN ISO 527 | MPa | 65 |
| Vrubová houževnatost | DIN EN ISO 179 | kJ / m2 | 2 |
| Tvrdost Shore | DIN EN ISO 868 | scale D | 85 |
| Tvrdost kuličkového vtisku | DIN EN ISO 2039-1 | MPa | 250 |
| Modul pružnosti v tlaku | DIN EN ISO 604 | MPa | 4000 |
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Teplota tání | ISO 11357-3 | °C | 337 |
| Provozní teplota dlouhodobá | Průměr | °C | -60...250 |
| Provozní teplota krátkodobá (max.) | Průměr | °C | 310 |
