Sustarin® C BIO (mb)

POM-C

QR-Code

Characteristics

  • Chemical resistance
  • Low moisture absorption
  • High abrasion resistance
  • ideal combination of tensile strength, stiffness and impact strength
  • Low creep tendency
  • Good machinability
  • favourable electric and dielectric behaviour
  • Good dimensional stability
  • Good sliding properties

Sustainability

  • Mass-balanced
  • Bio-based raw materials reduce the use of fossil raw materials

Technical Specifications Sustarin® C BIO (mb)

Test MethodUnitGuideline Value
DensityDIN EN ISO 1183-1g / cm31,41
Water absorptionDIN EN ISO 62%0,2
Flammability (Thickness 3 mm / 6 mm)UL 94HB / HB
Test MethodUnitGuideline Value
Yield stressDIN EN ISO 527MPa67
Elongation at breakDIN EN ISO 527%30
Tensile modulus of elasticityDIN EN ISO 527MPa2800
Notched impact strengthDIN EN ISO 179kJ / m26
Shore hardnessDIN EN ISO 868scale D81
Test MethodUnitGuideline Value
Melting temperatureISO 11357-3°C165
Thermal conductivityDIN 52612-1W / (m * K)0,31
Thermal capacityDIN 52612kJ / (kg * K)1,50
Coefficient of linear thermal expansionDIN 5375210-6 / K110
Service temperature, long termAverage°C-50 … 100
Service temperature, short term (max.)Average°C140
Heat deflection temperatureDIN EN ISO 75, Verf. A, HDT°C110
Test MethodUnitGuideline Value
Dielectric constantIEC 602503,8
Dielectric dissipation factor (50 Hz)IEC 602500,002
Volume resistivityDIN EN 62631-3-1Ω * cm1013
Surface resistivityDIN EN 62631-3-21013
Comparative tracking indexIEC 60112600
Dielectric strengthIEC 60243kV / mm40
