Matrox® U 110 green

PE — PE-UHMW - PE 1000

Matrox^® is outstanding for its extremely low coefficient of friction and high wear resistance and so optimally meets requirements for the lining of silos and bunkers.

Matrox^® U 110 contains oxidation-retardant additives for a longer service life in the higher temperature range.

light green

sheet

Characteristics

Extremely low coefficient of friction
Very good abrasion and wear resistance
High temperature resistance
Corrosion resistance
Nearly no moisture absorption
Good impact strength

Industries

Transporte de materiales a granel

Application Examples

Revestimientos para búnkeres y silos

Las grandes alturas de caída y el duro impacto de los productos a granel causan un desgaste extremo en búnkeres y silos. La salida en forma de tolva causa problemas de flujo de masas y granos. Las normas de seguridad o la manipulación de alimentos, por ejemplo, exigen requisitos complementarios a la hora de seleccionar los materiales de revestimiento apropiados.

Revestimientos para vehículos de minería

En los procesos de transporte, almacenamiento o procesamiento de materiales a granel, el desgaste y la formación de incrustaciones pueden causar interrupciones en el proceso de trabajo. El flujo de material se puede parar y el desgaste puede destruir la carrocería del camión. Nuestro material Matrox^® combina la mejor fricción superficial con la más alta resistencia a la abrasión, mejorando así las propiedades de flujo de sus sólidos a granel y evitando la abrasión incluso en condiciones operativas adversas.

Variants

	SKU	Name	Type	Color	Measurements	Length	Width	Thickness
Not in stock (MOQ)	257451	Matrox® U 110 green pressed	sheet	light green	2.000 x 1.000 x 10 mm	2.000 mm	1.000 mm	10 mm
Not in stock (MOQ)	349658	Matrox® U 110 green pressed	sheet	light green	4.000 x 2.000 x 20 mm	4.000 mm	2.000 mm	20 mm
Not in stock (MOQ)	354480	Matrox® U 110 green pressed	sheet	light green	6.000 x 2.500 x 15 mm	6.000 mm	2.500 mm	15 mm
Not in stock (MOQ)	367590	Matrox® U 110 green pressed	sheet	light green	6.000 x 2.000 x 8 mm	6.000 mm	2.000 mm	8 mm
Not in stock (MOQ)	368795	Matrox® U 110 green pressed	sheet	light green	6.000 x 2.500 x 10 mm	6.000 mm	2.500 mm	10 mm
Not in stock (MOQ)	375941	Matrox® U 110 green pressed	sheet	light green	3.000 x 2.000 x 25 mm	3.000 mm	2.000 mm	25 mm
Not in stock (MOQ)	376195	Matrox® U 110 green pressed	sheet	light green	6.000 x 2.000 x 25 mm	6.000 mm	2.000 mm	25 mm
Not in stock (MOQ)	401627	Matrox® U 110 green pressed	sheet	light green	3000 x 2000 x 20 mm	3.000 mm	2.000 mm	20 mm
Not in stock (MOQ)	401818	Matrox® U 110 green pressed	sheet	light green	6.000 x 2.000 x 20 mm	6.000 mm	2.000 mm	20 mm
Not in stock (MOQ)	412657	Matrox® U 110 green pressed	sheet	light green	2.000 x 2.000 x 12 mm	2.000 mm	2.000 mm	12 mm
Not in stock (MOQ)	426203	Matrox® U 110 green pressed	sheet	light green	6.000 x 2.000 x 15 mm	6.000 mm	2.000 mm	15 mm
Not in stock (MOQ)	431461	Matrox® U 110 green pressed	sheet	light green	6.000 x 2.000 x 10 mm	6.000 mm	2.000 mm	10 mm
Not in stock (MOQ)	445896	Matrox® U 110 green pressed	sheet	light green	2.000 x 1.000 x 5 mm	2.000 mm	1.000 mm	5 mm
Not in stock (MOQ)	454378	Matrox® U 110 green pressed	sheet	light green	2.000 x 1.000 x 10 mm	2.000 mm	1.000 mm	10 mm
Not in stock (MOQ)	454626	Matrox® U 110 green pressed	sheet	light green	3.000 x 1.000 x 6 mm	3.000 mm	1.000 mm	6 mm
Not in stock (MOQ)	454695	Matrox® U 110 green pressed	sheet	light green	6.000 x 2.000 x 6 mm	6.000 mm	2.000 mm	6 mm
Not in stock (MOQ)	458205	Matrox® U 110 green pressed	sheet	light green	2.000 x 1.000 x 110 mm	2.000 mm	1.000 mm	110 mm
Not in stock (MOQ)	460406	Matrox® U 110 green pressed	sheet	light green	6.000 x 2.500 x 12 mm	6.000 mm	2.500 mm	12 mm
Not in stock (MOQ)	461998	Matrox® U 110 green pressed	sheet	light green	2.000 x 2.000 x 8 mm	2.000 mm	2.000 mm	8 mm
Not in stock (MOQ)	462023	Matrox® U 110 green pressed	sheet	light green	6.000 x 2.000 x 12 mm	6.000 mm	2.000 mm	12 mm

Technical Specifications Matrox® U 110 green

General properties

	Test Method	Unit	Guideline Value
Density	DIN EN ISO 1183-1	g / cm³	>0,93
Water absorption	DIN EN ISO 62	%	<0,01
Flammability (Thickness 3 mm / 6 mm)	UL 94		HB
Molecular weight	-	10⁶ g/mol	∼ 9

Mechanical properties

	Test Method	Unit	Guideline Value
Elongation at break	DIN EN ISO 527	%	>50
Tensile modulus of elasticity	DIN EN ISO 527	MPa	>650
Notched impact strength	DIN EN ISO 11542-2	kJ / m²	>100
Shore hardness	DIN EN ISO 868	scale D	>63
Wear resistance	Sand-slurry		80
Sand Slurry	1018 Steel=10		∼ 80

Thermal properties

	Test Method	Unit	Guideline Value
Melting temperature	ISO 11357-3	°C	130 ... 135
Thermal conductivity	DIN 52612-1	W / (m * K)	0,40
Thermal capacity	DIN 52612	kJ / (kg * K)	1,90
Coefficient of linear thermal expansion	DIN 53752	10^-6 / K	150 ... 230
Service temperature, long term	Average	°C	-250 … 110
Service temperature, short term (max.)	Average	°C	130
Vicat softening temperature	DIN EN ISO 306, Vicat B	°C	80

Electrical properties

	Test Method	Unit	Guideline Value
Dielectric constant	IEC 60250		2,3
Dielectric dissipation factor (10⁶ Hz)	IEC 60250		0,0001
Volume resistivity	DIN EN 62631-3-1	Ohm * cm	10¹⁴
Surface resistivity	DIN EN 62631-3-2	Ohm	10¹⁴
Comparative tracking index	IEC 60112		600
Dielectric strength	IEC 60243	kV / mm	>40
