LubX® AST black
PE — PE-UHMW - PE 1000
black, similar RAL 9005
profilesheet
Characteristics
- Antistatic
- Good dry-running properties
- Good wear resistance
- Good sliding properties
Industries
Food Industry- Bakery and Confectionery
- Beverage Industry
Application Examples
Variants
| SKU | Name | Type | Type | Color | Measurements | Length | Width | Thickness | Height | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
| No stock item (MOQ) | 373451 | LubX® AST black extruded | Special profile | Special profile (R593) | black, similar RAL 9005 | 30.000 x 11,5 x 12 mm | 30,000 mm | 11.5 mm | 12 mm | ||
| No stock item (MOQ) | 418756 | LubX® AST black extruded | Special profile | Special profile (R699) | black, similar RAL 9005 | 6.020 (-0/+30) x 18,4 x 6 mm | 6,020 mm | 18.4 mm | 6 mm | ||
| No stock item (MOQ) | 460446 | LubX® AST black extruded | Special profile | Special profile (R779) | black, similar RAL 9005 | 3000 (-0/+30) x 17 x 6,2 mm | 3,000 mm | 17 mm | 6.2 mm | ||
| No stock item (MOQ) | 471221 | LubX® AST black extruded | Special profile | Special profile (R779) | black, similar RAL 9005 | 6000 (-0/+20) x 17 x 6,2 mm | 6,000 mm | 17 mm | 6.2 mm | ||
| No stock item (MOQ) | 510729 | LubX® AST black extruded | Clamp profile | Clamp profile (R745) | black, similar RAL 9005 | 25.000 x 10,2 x 6,2 mm | 25,000 mm | 10.2 mm | 6.2 mm | ||
| No stock item (MOQ) | 510731 | LubX® AST black extruded | Special profile | Special profile | black, similar RAL 9005 | 4.000 (-0/+50) x 25,09 x 5,5 mm | 4,000 mm | 25.09 mm | 5.5 mm | ||
| No stock item (MOQ) | 380271 | LubX® AST black pressed | sheet | sheet | black, similar RAL 9005 | 15 x 1000 x 2000 mm | 2,000 mm | 1,000 mm | 15 mm | ||
| No stock item (MOQ) | 401972 | LubX® AST black pressed | sheet | sheet | black, similar RAL 9005 | 50 x 1000 x 2000 mm | 2,000 mm | 1,000 mm | 50 mm | ||
| No stock item (MOQ) | 443420 | LubX® AST black pressed | sheet | sheet | black, similar RAL 9005 | 20 x 1000 x 2000 mm | 2,000 mm | 1,000 mm | 20 mm | ||
| No stock item (MOQ) | 443440 | LubX® AST black pressed | sheet | sheet | black, similar RAL 9005 | 20 x 2000 x 6000 mm | 6,000 mm | 2,000 mm | 20 mm | ||
| No stock item (MOQ) | 450813 | LubX® AST black pressed | sheet | sheet | black, similar RAL 9005 | 25 x 2000 x 6000 mm | 6,000 mm | 2,000 mm | 25 mm | ||
| No stock item (MOQ) | 463802 | LubX® AST black pressed | sheet | sheet | black, similar RAL 9005 | 15 x 2000 x 6000 mm | 6,000 mm | 2,000 mm | 15 mm |
Technical Specifications LubX® AST black extruded
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Density | DIN EN ISO 1183-1 | g / cm3 | 0,94 |
| Water absorption | DIN EN ISO 62 | % | 0,01 |
| Flammability (Thickness 3 mm / 6 mm) | UL 94 | HB |
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Yield stress | DIN EN ISO 527 | MPa | 20 |
| Elongation at break | DIN EN ISO 527 | % | >50 |
| Tensile modulus of elasticity | DIN EN ISO 527 | MPa | 650 |
| Notched impact strength | DIN EN ISO 179 | kJ / m2 | no break |
| Shore hardness | DIN EN ISO 868 | scale D | 60 |
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Melting temperature | ISO 11357-3 | °C | 133 – 135 |
| Coefficient of linear thermal expansion | DIN 53752 | 10-6 / K | 150 - 230 (*) |
| Service temperature, long term | Average | °C | -150 … 80 (*) |
| Service temperature, short term (max.) | Average | °C | 130 (*) |
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Surface resistivity | DIN EN 62631-3-2 | Ω | 109 |
Technical Specifications LubX® AST black pressed
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Density | DIN EN ISO 1183-1 | g / cm3 | 0,94 |
| Water absorption | DIN EN ISO 62 | % | 0,01 |
| Flammability (Thickness 3 mm / 6 mm) | UL 94 | HB |
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Yield stress | DIN EN ISO 527 | MPa | 20 |
| Elongation at break | DIN EN ISO 527 | % | >50 |
| Tensile modulus of elasticity | DIN EN ISO 527 | MPa | 650 |
| Notched impact strength | DIN EN ISO 179 | kJ / m2 | no break |
| Shore hardness | DIN EN ISO 868 | scale D | 60 |
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Melting temperature | ISO 11357-3 | °C | 133 – 135 |
| Coefficient of linear thermal expansion | DIN 53752 | 10-6 / K | 150 - 230 (*) |
| Service temperature, long term | Average | °C | -150 … 80 (*) |
| Service temperature, short term (max.) | Average | °C | 130 (*) |
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Surface resistivity | DIN EN 62631-3-2 | Ω | 109 |
